Steering Parts

Rs5000 steering damper
Part # RS5415 | Line Code: MON
brandNameImage
brandNameImage

$140.80
error
Not Fitted

Product Details
expand_less
Dust Shield Included Yes
Compressed Length 410.5
Extended Length 709.7
Lower Mounting Code L1
Lower Mounting Description Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL
Upper Mounting Description Loop Bushing & Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL
Upper Mounting Code LS26
Most Popular Year 2017
Most Popular Make / Model Ford F-250 Super Duty
Min Year Covered 2011
Extended Bumper Stop No
Extended Hydraulic Lockout No
Compressed Bumper Stop No
Product Grade Premium
Max Year Covered 2020
Cubre polvo Yes
Viaje 11.780
Accesorio(s) P01385
Parts Pack(s) P01385
Lower Mount Type Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL
Tipo de Montura Inferior Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL
Tipo de Montura Superior Loop Bushing & Sleeve Mount - 12MM Sleeve ID X 38.1MM Sleeve OAL
Parts Pack P01385
Total Part VIO 2146868
Reserve Tube Diameter (INCH) 1.86
Travel Length (INCH) 11.78
Compressed Length (INCH) 16.16
Extended Length (INCH) 27.94
Reserve Tube Diameter 1.86
Travel Length 11.78
Body Diameter 1.86
Lower Mount Code L1
Upper Mount Code LS26
Part Description Steering Damper
Hydraulic Lockout No
Includes Bump Stop No
Internal Rebound Bumper No
Upper Mount Type Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL
Dust Shield Yes
Part Terminology Steering Damper

Features & Benefits
expand_more
Ideal for off-road driving, towing and street applications, Rancho® RS5000® steering stabilizers enhance a vehicles performance and minimize on- and off-road driver fatigue by reducing wheel shimmy, bump steer and vibration.

Application Summary
expand_more

2011-2022 Ford F-250 Super Duty (Front) (Drive: 4WD / Qualifier: Single Steering Damper, with OEM Steering Damper Mounts); 2011-2022 Ford F-350 Super Duty (Front) (Drive: 4WD / Qualifier: Single Steering Damper, with OEM Steering Damper Mounts); 2011-2022 Ford F-450 Super Duty (Front) (Qualifier: Replaces OE Part Number(s) BC3Z3E651A, BC3Z3E651B, HC3Z3E651B, HC3Z3E651C, HC3Z3E651D, Single Steering Damper, with OEM Steering Damper Mounts); 2011-2022 Ford F-550 Super Duty (Front) (Qualifier: Replaces OE Part Number(s) BC3Z3E651A, BC3Z3E651B, HC3Z3E651B, HC3Z3E651C, HC3Z3E651D, Single Steering Damper, with OEM Steering Damper Mounts)
