| Combustion Seal Design | Embossed Steel Bead |
| Materials/Construction | Embossed steel shim w/coating |
| Mfg. | GM Performance |
| Heavy Duty Supplier | Yes |
| Material | Embossed steel shim w/coating |
| Application Notes | Cast iron or aluminum heads - Used in Sportsman drag race and flat top piston oval track categories |
| Engine Family | Chevrolet V8 Small Block |
| Bore Size (in.) | 4.100 |
| Thickness | 0.015 |
| Combustion Chamber Volume (cc) | 3.200 |
| Gasket Sealant Included | No |
| Cylinder Bore Diameter | 4.100 |
| Engine Displacement | 262, 265, 267, 283, 302, 305, 307, 327, 350 |
| Grade Type | Performance |
| Thickness (in.) | 0.015 |
| Part Type | Head Gasket |
| Product Notes | Do not use on 400 Engs.; Do not use on aluminum blocks w/liners; No brinelling of aluminum heads |
| Part Terminology | Engine Cylinder Head Gasket |
